VPC vs. VPS Pumps: Differences, Features, and How to Choose the Right One

When a system requires increased water pressure, reliable water supply, or specific flow and pressure conditions, vertical multistage pumps are an efficient and versatile solution.

The VPC and VPS series are non-self-priming, vertical multistage pumps designed for in-line installation. Both feature stainless-steel hydraulic components and are available in different power ratings and numbers of stages to meet a wide range of applications.

But what is the difference between a VPC and a VPS pump? Below, we explain their main features, differences, applications, and how to choose the right option for your system.

What Are VPC and VPS Pumps?

VPC and VPS pumps are vertical multistage centrifugal pumps designed for applications where reliable water pressure and flow are required.

Their multistage design allows the pump to achieve different pressure levels depending on the selected model and number of stages.

Key features include:

• Vertical multistage design.
• Non-self-priming configuration.
• In-line installation with flanged connections.
• Impellers, diffusers, and pressure casings made of stainless steel.
• Short-coupled pump and motor shaft design.
• Cartridge-type mechanical seal.
• IPX5 motor protection.
• Different power ratings and numbers of stages.
• Fluid temperatures of up to 120 °C, depending on the configuration and application.
• Maximum efficiency at approximately 17 gpm, under the corresponding operating conditions.

This range of configurations makes it possible to select a pump according to the required flow and pressure.

VPC vs. VPS: What Is the Difference?

The main difference between the VPC and VPS series is the construction of the pump base.

VPC Pump

The VPC series features a cast-iron base, while its main hydraulic components are made of stainless steel.

It is a reliable option for water pressure boosting, water supply systems, and industrial applications where a vertical multistage pump is required.

VPS Pump

The VPS series features a stainless-steel base.

This provides a higher level of stainless-steel construction throughout the pump assembly, making it an interesting option for applications where greater resistance of the exposed components is desired.

VPC vs. VPS Comparison

*Maximum temperature depends on the specific pump configuration and operating conditions.

Why Choose a Vertical Multistage Pump?

One of the main advantages of these pumps is their ability to generate higher pressures through multiple hydraulic stages, while maintaining a compact vertical design that can be easily integrated into different installations.

The VPC and VPS series are available with different combinations of motor power and number of stages. This allows users to select a pump that better matches the requirements of their system.

The correct pump should be selected based on:

Required flow + required pressure + fluid characteristics + installation conditions.

Pump selection should not be based on horsepower alone. It is important to review the pump performance curve and ensure that the operating point falls within the recommended range.

Applications of VPC and VPS Pumps

Thanks to their multistage configuration, these pumps can be used in a wide variety of applications.

1. Water Supply and Pressure Boosting

They are suitable for systems where increased water pressure is required, including:

• Buildings.
• Hotels.
• Residential applications.
• Pressure-boosting stations.
• Water supply networks.
• Industrial water supply systems.

2. Light Industry

They can be used in various industrial processes, including:

• Washing and cleaning systems.
• Car wash facilities.
• Fire protection systems.
• Water processing systems.
• Machine tools.
• Cooling and lubrication systems.

3. Heating, Ventilation, and Air Conditioning

Vertical multistage pumps can also be integrated into HVAC and temperature-control systems, including:

• Boilers.
• Induction heating.
• Heat exchangers.
• Cooling systems.
• Cooling towers.
• Temperature-control systems.

4. Irrigation and Agriculture

In agricultural applications, they can be used for:

• Sprinkler irrigation systems.
• Greenhouses.
• Water supply and pressure-boosting systems.

5. Water Treatment and Filtration

These pumps can also be used in different water treatment processes, such as:

• Water softening and demineralization systems.
• Reverse osmosis systems.
• Distillation systems.
• Ultrafiltration systems.

Cartridge-Type Mechanical Seal: An Advantage for Maintenance

Both the VPC and VPS series feature a cartridge-type mechanical seal, designed to simplify maintenance operations.

Depending on the application, configurations with silicon carbide/EPDM or silicon carbide/Viton mechanical seals are available, allowing the appropriate materials to be selected according to the fluid characteristics and operating conditions.

One of the main advantages of the cartridge design is that the seal can be replaced quickly, without requiring special tools or complete pump disassembly.

This helps simplify maintenance and can reduce equipment downtime.

VPC or VPS: Which One Should You Choose?

The answer depends primarily on the installation requirements and the level of resistance desired from the pump construction.

If you are looking for a vertical multistage pump with a cast-iron base, the VPC series may be the right alternative.

If you prefer a configuration with a stainless-steel base, the VPS series may be the option to consider.

However, the final selection should always be based on the hydraulic requirements of the system, including flow rate, pressure, motor power, number of stages, temperature, and fluid characteristics.

In Summary

VPC: Vertical multistage pump with a cast-iron base.

VPS: Vertical multistage pump with a stainless-steel base.

Both series provide reliable solutions for pressure boosting, water supply, industrial applications, agriculture, HVAC, and water treatment, with different configurations available to meet the requirements of each installation.

Find the Right Pump for Your System

Selecting the right pump is essential for achieving efficient and reliable system performance. Before choosing a VPC or VPS model, it is important to determine the required flow and pressure and review the technical specifications of the corresponding model.

Need help choosing between VPC and VPS? Review the specifications of each model and select the configuration that best fits your project requirements.
