Jet Pump Pearl IRONJET for Shallow Wells and Irrigation Applications

Built with durable materials and suitable for outdoor installations, the IRONJET pump is ideal for domestic water systems, garden irrigation, and pressure boosting applications. Each unit is factory‑assembled with a PEARL pressure switch, allowing quick installation and dependable pressure control.

High‑quality components and continuous duty construction provide long service life, making this pump a versatile solution for both water supply from shallow wells and low‑to‑medium demand irrigation systems.

Applications

• Shallow well domestic water supply
• Irrigation and garden watering systems
• Pressure boosting from flooded suction applications
• Handling water containing air or other gases

Operating Conditions & Technical Features

• Pump Type: Closed‑coupled self‑priming centrifugal jet pump
• Liquid Temperature Range: 32°F to 150°F
• Maximum Working Pressure: 125 PSI
• Duty Rating: Continuous duty
• Motor Options:
  • ½ – ¾ HP: Capacitor start / capacitor run
  • 1 – 1½ HP: Permanent Split Capacitor (PSC)
• Voltage: 115 / 230 V, single phase
• Horsepower: ½, ¾, 1, 1½ HP
• Motor Standard: NEMA ODP 56J
• Thermal Overload Protection: Included
• Maximum Ambient Temperature: 104°F (40°C)
• Connections: Threaded NPT ports
• Maintenance Features:
  • Pre‑drilled priming port with plug
  • Pre‑drilled drain port with plug

Construction & Materials

• Pump Casing: Cast Iron
• Impeller: PPE + PS with SS304 inserts
• Diffuser: PP volute with SS304 wear ring
• Shaft: SS304 + 40Cr
• Mechanical Seal: SiC / SUS316 / EPDM
• Hardware: Stainless Steel

The IRONJET jet pump offers dependable performance for shallow well pumping and irrigation use, combining self‑priming capability, durable construction, and reliable pressure control in a single versatile pump.
